The gate structure, frame and door, ø3cm drive screw. ø25cm, manual turntable, tightening guides, door reinforce pipe, 1.5t x3 x6cm, fixing screws and iron pieces and accessories are using the rest of parts all in # 304 stainless steel, provide in material documents.

Using the electric motor in AC1.5P-220V/380V, screw elevator SR-15T ratio 1/1, as in the energized state, using ø20cm operation manually turntable.

waterproof material is EPDM,  four point jagged waterproof, weather resistance and high temperature of 160℃ , to avoid falling into cracks aging, provide in material documents.

Close the gates at more than 99% of the fully waterproof.

The special design in this gate is drive screw hidden closed (at the door rises towards the screw will not rise) , To facilitate rotate the turntable in the hand is not knocked against screw and turn on and off gate quickly.
